1. Keep the battery charged and can be connected full time without overcharging;
2. Temperature-compensated to ensure optimum charge voltage according to ambient temperature;
3. Unique Gel Cell battery adjusted software allows for a slightly lower charge voltage and higher store voltage to protect sensitive true Gel Cell batteries;
4. Multi-stage charging program allows for optimal constant battery levels without overcharging;
5. Automatically switches to float/mainenance voltage mode after fully charging the battery.
| Parameter | LC-2171 | LC-2101 | LC-2168 | LC-2169 | LC-2170 |
| Input Voltage | 100~240VAC | 100~240VAC | 100~240VAC | 100~240VAC | 100~240VAC |
| Output Frequency | 50~60Hz | 50~60Hz | 50~60Hz | 50~60Hz | 50~60Hz |
| Output Voltage | 12V | 24V | 24V | 24V | 24V |
| Output Current | 6A | 5A | 3.5A | 3A | 2A |
| Battery Type (AH) | 20-60 | 16.7-50 | 11.7-35 | 43403 | 6.7-20 |
| Light Switching Current | 1200mA | 1000mA | 700mA | 600mA | 400mA |
| Overload Protection | Yes | Yes | Yes | Yes | Yes |
| Short Circuit Protection | Yes | Yes | Yes | Yes | Yes |
| Reverse Polarity Protection | Yes | Yes | Yes | Yes | Yes |
| Charging Status Display | LED | LED | LED | LED | LED |
| Case | Plastic | Plastic | Plastic | Plastic | Plastic |
| Dimension (MM) | 165*95*60 | 165*95*60 | 165*95*60 | 165*95*60 | 165*95*60 |
| Certfication | CE/ETL | \ | CE/ETL/GS | CE/ETL/GS | CE/ETL/GS |
