1. Input Voltage 12V /24V/48V DC optional.
2. Output Voltage 115V /230V AC optional.
3. Portable power for AC products, AC outlets for connecting multiple loads.
4. High surge capacity for products that require more power to start.
5. High efficiency converts virtually all of the battery's power to AC.
6. Mounting brackets for convenient installation.
7. Heavy duty stud-connection mounting.
8. Overload protection, input reverse protection, short circuit protection.
| Parameter | MSI-100 | MSI-150 | MSI-200 | MSI-300 |
| Continuous Output Power (Watt) | 100 | 150 | 200 | 300 |
| OutputPeakPower(Watt) | 200 | 300 | 400 | 600 |
| InputVoltage (DC) | 12V(11~15V)/24V(21~29 ) V/48V(42~58V) | |||
| Output Voltage(AC) | 100~120V/220~240V | |||
| Frequency | 50Hz/60Hz±3Hz | |||
| OutputWaveform | Modifiedsinewave | |||
| Efficiency | 85~90% | |||
| LowBattrey-voltageAlarm (Volt) | 10.5V±0.5V/21±1V/42±2V | |||
| Low Battrey-voltageShutdown (Volt) | 10V±0.5V/20±1V/40±2V | |||
| Overtemperatureshutdown | <65°C | |||
| Available Protection | overloadprotection,inputreverseprotection,shortcircuit protection | |||
| CoolingMode | By Fan | |||
| ReplaceableFuse | 15A | 20A | 25A | 35A |
| Accessory | Cigarette lighter(included) | |||
| Dimension (L*W*H)mm | 95*70*46 | 105*70*46 | 125*90*46 | 125*90*46 |
| Weight (KGS) | 0.35 | 0.36 | 0.5 | 0.55 |
