Ideal eco-friendly solution with electric power
High powerful 96V 15KW AC motor
Macpherson independent suspension
Comfortable seats with ergonomic design
Multi-functional dashboard
Consistent and efficient electric drive-train
1. Standard color: White; attractive appearance with strong carrying capacity
2. Ideal eco-friendly solution with electric power
3. High powerful 96V 15KW AC motor
4. Macpherson independent suspension
5. Equipped with comfortable seats with ergonomic design
6. Convenient with maintenance free batteries
7. Accept to be customized to meet reqiurements of customers
| Battery | 6V*16PCS | Minimum turnin radius(m) | 7.4 |
| Motor | AC 96V 15KW | Max.climbing ability (loaded) | 15% |
| Controller | 72V 550A | Overall dimensions(mm) | 5850*1800*2180 |
| Charger | On Board Charger | Max.loading weight(kgs) | 1955 |
| Suspension: | Macpherson independent suspension | Netweight(kgs) | 1890 |
| Steering | Gear rack steering system | Chassis | Steel |
| Braking system | Four wheels hydraulic braking system | Wheelbase(mm) | 3485 |
| Passenger capacity | 23 | Ground clearance(mm) | 155 |
| Range (loaded)(km) | 80km | Tires: | 195 70R15C |
| Max.speed (km/h) | 30 | Quantity per Container | 2pcs/20ft.4PCS/40HQ |
| STANDARD CONFIGURATION: | ||
| DESCRPTIONS | REMARKS | |
| Body | Fiber glass body | |
| Roof | Steel frame and fiber glass cover | |
| Windshield | One-piece see-through laminated windshield with wiper | |
| Lighting system | LED front lights, tail lights,turinglights, brake lights | |
| Mirrors | Side mirrors,inner mirror | |
| Dashboard | Speedometer combined with battery capacity indicator, driving speed indicator, etc. | |
| OPTIONAL CONFIGURATION/ACCELERATORS: | ||
| Electric fan, card reader, CD player, megaphone, loudspeaker, waring alarm, alarm switch, etc. | ||
| COLORS: | ||
| Accept customization | ||
