1. Designed to suit the housekeeping needs of hotel and resort operations, tourist spots, aged care facilities,s and other service organizations.
2. A 5KW electric AC motor Provides powerful driving and climbing ability.
3. Vertically integrated production process ensures premium quality and reliability.
| Motor | AC 48V 5 KW | Large Range | 60 KM |
| Controller | 48V 450A | Speed (km/h) | 25-28 km/h |
| Battery | Marxon Lithium Ion Battery 51.2V 150Ah | Turning Radius | 4.5 m |
| Charger | OnBoard 48V 20A Charger | Brake Distance | 6 m |
| Overall dimensions | 3500 * 1290 * 2010 mm | Rear Cargo bed Dimension & Payload | 1200 * 1150 * 310 mm 500 KGS, Hydraulic Tipping |
| Wheelbase | 2430 mm (+/- 10 mm) | Climbing Capacity | 20 % |
| Front-wheel Tread | 960 mm (+/- 10 mm) | Rear wheel Tread | 1010 mm (+/- 10 mm) |
| Standard Configuration | 1. Windshield Foldable Acrylic Front Windshield 2. Dashboard In black plastic finish, forward/reverse switch, ignition key, USB Port; 3. Beverage holders 4 cups drink holders 4. Speedometers 7-inch speedometers, with backup camera. 5. Score card holder on the steering wheel 6. With side-view mirrors 7. The Body Front Cowl is a Plastic Cover, and the Rear Body is an aluminum profile panel 8. Roof Injection PP Plastic Roof 9. Steering system Self-compensating "rack & pinion" steering 10. Light System Complete headlights, 2 front turn signals, 2 taillights( each combined 1 brake light with 1 turn signal), with DC-DC converter (converting from 48V to 12V), horn. ALL LED Lights(Emark and DOT Certificated) 11 . Accelerator Adjustable Inductive Accelerator Continuously Variable Speed System 12. Driving mode Rear axle two-stage deceleration, motor direct driving 13. Rear axle Integrated, Gear ratio 14:1 | ||
