Electric Ambulance Car DG-C2A

Excellent hill climbing ability

Premium quality and reliability

Consistent and efficient electric drive-train


Electric Ambulance Car DG-C2A

Electric Customzied Cart Features

Emergency happens all the time. For larger golf courses, resorts, sightseeing spots, airports or government bases, Marshell's electric ambulance cars will always be with you to save the emergency. Marshell is dedicated to individual markets with full service and support to match.


Electric Customzied Cart Specifications
ModelDG-C2A Gross weight:520kg
Passenger  capacity:3Max. loading weight of  whole car320kg
Battery:8V170AH*6Bed size1700*540*100mm
Motor:DC 48V3KW/ AC  4KW Steering:Rack&Pinion'' Sreering
Controller:Curtis 1266A  DC275A/48V AC  Toyota/AC Curtis Brakes:Rear Wheel Mechanical  Drum Brake
Charger:48V/18ATire:18*8.50-8, 4Ply
Max.Speed:25km/hGround  clearence:100mm(full load)
Max.travelling  range :80kmOverall  dimension:2720*1180*1890mm
Climbing capacity:30%Qty per container:8pcs/20GP 17pcs/40HQ
Brake Range: 4.5mStandard parts:Stretcher, Ambulance  box, Fire extinguisher
Minmum Turning radius:5m Optional parts:

Lighting system,Side mirrior, Inner mirrior, Seat belts, Weather enclosure, Sunshade curtain, Police light,   PA system, Media player,10'' Alloy wheel, Trojan battery
